Description
A mathematician named DeMorgan developed a pair of important rules regarding group complementation in Boolean algebra. By group complementation, referring to the complement of a group of terms, represented by a long bar over more than one variable.
logic gates that inverting all inputs to a gate reverses that gate’s essential function from AND to OR, or vice versa, and also inverts the output. So, an OR gate with all inputs inverted (a Negative-OR gate) behaves the same as a NAND gate, and an AND gate with all inputs inverted (a Negative-AND gate) behaves the same as a NOR gate. DeMorgan’s theorems state the same equivalence in “backward” form: that inverting the output of any gate results in the same function as the opposite type of gate (AND vs. OR) with inverted inputs.
HIGHLIGHTS
- Important rules regarding group complementation
- Logic gates that inverting all inputs to a gate reverses that gate’s essential function from AND to OR, or vice versa
- DeMorgan’s theorems state the same equivalence in “backward”
BLOCK DIAGRAM
HARDWARE REQUIREMENTS
- IC 7400
- IC 7432
- IC 7404
SOFTWARE REQUIREMENTS
- Eagle
