Description
The project is designed to develop an automatic water flow measurement system that displays flow rate. use of proper method of measurement is important. The advantage of using this method is to reduce human intervention.
The project uses an Arduino board which is programmed to receive the input signal of varying flow rate condition of the pump through a Flow sensor arrangement. This is achieved by interface between the sensing arrangement and the Arduino. Once the controller receives this signal, it generates an output that drives LCD display is also interfaced to the Arduino controller to display the status of the water flow rate.
The concept in future can be enhanced by integrating GSM technology, such that whenever the water flow rate changes low to high . SMS is delivered to the concerned person regarding the status of the water flow rate measurement.
HIGHLIGHTS
- Water flow measurement
- Arduino is used to control
- flow sensor is interfaced to Arduino
- Flow rate shows on LCD display
BLOCK DIAGRAM
HARDWARE REQUIREMENTS
- Arduino
- Flow sensor
- LCD Display
- Transformer
- Submersible pump
- Pipe
SOFTWARE REQUIREMENTS
- Arduino
- Eagle
- proteus
